Backup Power Supply

v0.0.1

The Backup Power Supply

The Ficsit Backup Power Supply manages backup power - sort of like a UPS but too slow to guarantee uninterrupted power. Or is it?

Setup

To use the Ficsit BPS, you will need one or more power storages, plus two power switches and of course a computer. The switches must be hooked up as shown below:

 mains power    load    power storage
      |           |           |
      |           |           |
      +-----/ ----+----/ -----+

          mains     power storage
         switch        switch

A demonstration setup is shown below:

Example setup of the Ficsit Backup Power Supply Example setup of the Ficsit Backup Power Supply

Please observe the following:

  • the mains switch must have the following nick: "BPS mainsSwitch"
  • the power storage switch must have the following nick: "BPS powerStorageSwitch"
  • the computer needs to have a network connection to both switches and a power storage.

Operation and functioning

Once operational, the Ficsit Backup Power Supply will not need any attention from the employee.

The Ficsit BPS will monitor the grid and the connected power storage(s). When the overall load on the grid exceeds the production, it will disconnect itself from the grid and engage the power storage(s) so you can continue operating from the power storage(s) as long as there is any charge left in the power storage(s). Then, when the grid is balanced again, it will start charging the power storage(s).

Normal operation The Ficsit BPS during Normal operation

Charging The Ficsit BPS while Charging

Providing backup power The ficsit BPS providing backup power

Considerations for designing your grid

To guarantee grid stability, Ficsit advises to have a minimum of one power storage connected directly to the grid. This ensures there will be enough power available for the limited amount of time it takes for your Backup Power Supply management system to flip its switches.

Please note that while the charge rate of a power storage is limited to 100 MW, its discharge rate is unlimited. This means that for the maximum of five seconds it takes for the BPS to provide backup power, a single power storage can supply as much as 72,000 MW of power.

EEPROMs

EEPROM EEPROM.lua

The main EEPROM used when installing this package. The name is not relevant.
